AISI 304 stainless steel braided
Türkiye's first TSE-certified flex hose
Flexible connection hoses that pass a 155 bar burst test, safe for drinking water and food use. For basins, sinks, cisterns, water heaters and boilers.
155 bar
Burst test
10 years
Warranty
168 countries
Groupama insurance
100%
Made in Türkiye
Why Mistillo flex hoses?
Every part that touches your water and your health is carefully chosen.
Drinking-water safe
The EPDM / PEX inner hose is suitable for contact with drinking water.
Carcinogen-free
Made from raw materials free of harmful, carcinogenic substances.
Skin-safe
Water flows through a drinking-water safe EPDM / PEX inner hose, so nothing harmful to your skin gets into it.
Rust-proof
0.18 mm AISI 304 stainless steel braid resists moisture and corrosion.
Burst-resistant
155 bar burst test: more than 15 times the operating pressure.
Food-use safe
Used safely on kitchen sinks and mixers.
90 °C hot water
90 °C operating temperature for water heaters, boilers and hot water lines.
Flexible, easy to install
26 mm minimum bend radius for easy installation even in tight spaces.
Certificates and compliance
Technical values
| DN8 | DN12 (large bore) | |
|---|---|---|
| Operating pressure | 10 bar | 10 bar |
| Test pressure | 52 bar | 52 bar |
| Burst test pressure | 155 bar | 95 bar |
| Operating temperature | 90 °C | 90 °C |
| Nominal flow at 3 bar | 30 l/min | 60 l/min |
| Minimum bend radius | 26 mm | 26 mm |
| Inner / outer diameter | 8 / 12 mm | 12 / 16 mm |
Anatomy of a hose
Every part chosen for drinking water and long service life.
- ANickel-plated MS 58 brass nut
- BDrinking-water safe marked washer
- CNickel-plated MS 58 brass pin
- DDrinking-water safe EPDM or PEX inner hose
- E0.18 mm AISI 304 stainless steel braid
- HCold-sealed 0.45 mm AISI 304 stainless steel ferrule
Inner hose options
EPDM
Drinking-water safe EPDM rubber inner hose. Straight, elbow and large-bore (DN12) models for water heaters and boilers.
mpex®
Series with a drinking-water safe PEX inner hose. Straight and elbow models.
